Truck Canopy or Trailer Slimline II Rack Kit / 1255mm(W) X 1560mm(L)

* For illustrative purposes only. Please refer to the specs tab for detailed information.

1 Review

Truck Canopy or Trailer Slimline II Rack Kit / 1255mm(W) X 1560mm(L)

Front Runner

SKU: KRCA034T

$1,30000

US$1,300.00

This Rack Kit is for truck canopies/camper shells/caps and trailers that have roof top sizes no larger than approximately 1255mm/49.4" (W) x 1560mm/61.4" (L). The Slimline II Tray mounts to six (6) supplied Feet that slide in to the supplied Track. The 1500mm/59” long pair of tracks can be easily mounted to your canopy/shell or trailer.

See the Track installation instructions in the INSTALL tab for further details.

Earn 1300 Explorer Rewards Points

Proven gear and advice

You can trust

14 day money back

Guarantee

Built off-road

Tough

REVIEW HIGHLIGHTS

Canopy slimline rack

Great rack and easy to assemble. Very strong and light. Ideal for what it is designed for. Front runner rails are perfect and are much better than the large rails that were on my canopy. Would recommend. Thanks again. Graham

Graham V.

MORE REVIEWS

Info

This Rack Kit is for truck canopies/camper shells/caps and trailers that have roof top sizes no larger than approximately 1255mm/49.4" (W) x 1560mm/61.4" (L). The Slimline II Tray mounts to six (6) supplied Feet that slide in to the supplied Track. The 1500mm/59” long pair of tracks can be easily mounted to your canopy/shell or trailer.See the Track installation instructions in the INSTALL tab for further details.

All Front Runner Rack Kits contain installation instructions as well as all the components needed to mount the Slimline II Tray to your vehicle.

All Front Runner Racks are backed by a Limited Lifetime Warranty*

Specs

KRCA034T - Truck Canopy or Trailer Slimline II Rack Kit / 1255mm(W) X 1560mm(L) - by Front Runner

Consisting of:

3x FASS024 - Foot Set / 50mm - 60mm
1x RRSTD08 - SLII Tray - 1255mm(W)X1560mm(L)
1x TRCA004 - Canopy Tracks / 1500mm(L)

Material Used:

Black epoxy powder - coated T6 aluminium

High strength steel

Approximate Installed Weight: 28.46kg (62.74lbs)

The t-slots on the tops and bottoms of the rack tray slats and edge profiles accommodate standard 8mm bolts.

To determine the approximate height from your vehicle’s roof to the top of your Slimline II Roof Rack, add the height of the Slimline II Tray (50mm/2") to the height of the Foot or Grab-on Foot listed above.

If your Slimline II Roof Rack kit uses Legs, add the height of the Slimline II Tray (50mm/2") to the height of the Legs to determine the height of the rack from your vehicle's rain gutters.

If your Slimline II Roof Rack kit uses Foot Rails, add the height of the Slimline II Tray (50mm/2") to the height of the Foot Rails to determine the height of the rack from the crown (highest point) of the vehicles roof.

Shipping Dimensions:

Width: 445mm (18")

Length: 1730mm (68")

Height: 270mm (11")

Shipping Weight:

Weight: 31.2kg (69lbs)

Install

Installation Instructions for FASS024 (EN)
